Universal multimeter Uni-t UT53
Universal multimeter Uni-t UT53
Universal multimeter Uni-t UT53
Universal multimeter Uni-t UT53
Universal multimeter Uni-t UT53

Produkta tonis un faktiskā krāsa var atšķirties no attēlā redzamā, jo attēli ir ilustratīvi. Produkta apraksts ir vispārīgs un, iespējams, tajā nav iekļautas visas produkta īpašības.

Universal multimeter Uni-t UT53

39,00 €
Ikm. maksa no 1.90
2260939

MIE0016

5901436740698

Piegāde 6-10 d.d.

Skaits
Šī prece Jūs ieinteresēja
(Lasīt pakalpojumu sniegšanas noteikumus)

Multimeter Uni-t UT53 is a universal multimeter whose functions allow you to measure various physical values, including the voltage and intensity of direct and alternating current, which will allow you to determine the fault of the electrical installation.
Technical data:

  • Constant voltage: 200mV / 2V / 20V / 200V / 1000V ± (0.5% + 1)
  • AC voltage: 200mV / 2V / 20V / 200V / 750V ± (0.8% + 3)
  • Continuous current: 2 mA / 20 mA / 200 mA / 20 A ± (0.8% + 1)
  • Alternating current: 20 mA / 200 mA / 20 A ± (1% + 3)
  • Resistance: 200 ohms / 2 kOhm / 20 kOhm / 200 kOhm / 2 MOhm / 20 MOhm / 200 MOhm ± (0.8% + 1)
  • Capacitance: 2 nF / 20 nF / 200 nF / 2 µF / 20 µF ± (4% + 3)
  • Temperature: -20°C - 1000°C ± (1% + 3)
  • Diode test
  • hFE measurement of transistors
  • Continuity check
  • Manual change of measurement ranges
  • Low battery indicator
  • Automatic shutdown
  • DC Input Impedance: About 10 MOhm
  • Number of measurements: 2-3/s
  • Power supply: 9V battery (6F22)
  • Display size: 33 x 65 mm (3 1 digits)
  • Product dimensions: 190 x 88 x 34 mm
  • Product weight: 580 g

In the set:

  • Battery
  • Test leads
  • Temperature probe
  • Case
