MultiBAS SW-9108 ProfiSET TELMOR

327,00 €
Ikm. maksa no 9.32
3584741

SW-9108

5902887089329

Piegāde 2-5 d.d.

Maksājumi 5x65.40€
Skaits
Šī prece Jūs ieinteresēja
(Lasīt pakalpojumu sniegšanas noteikumus)
Frequency range :
  • 87 MHz ... 112 MHz - FM,
  • 170 MHz ... 240 MHz - VHF / DAB,
  • 470 MHz ... 694 MHz - UHF1, UHF2
  • 950 MHz ... 2150 MHz - SAT
  • Strengthening :
  • 15 dB @ FM
  • 15 dB @ VHF/DAB
  • 25 dB @ UHF1, UHF2
  • -2 dB ... 6 dB @ SAT
  • Inputs : 8 pcs.
    Outputs :
  • 8 pcs.
  • 5 pcs. (Signal loop-through)
  • Preamplifier power supply : 12 V DC : 50 mA / VHF/DAB, UHF1, UHF2 input
    Gain adjustment : -20 dB ... 0 dB (for single rail)
    Maximum output level DIN45004B : > 95 dBµV - FM
    > 95 dBµV - VHF
    > 95 dBµV - UHF1, UHF2
    > 94 dBµV - SAT
    Reflection : > 10 dB
    Sound/noise ratio : < 17 dB - FM
    < 10 dB - VHF
    < 12 dB - UHF1, UHF2
    Main features :
  • ProfiSETT product series
  • DVB-T, DVB-T2, DAB, DAB+ compliance
  • Dual UHF input for devices that need to receive from different directions
  • 5G Protected Technology
  • Smooth gain adjustment
  • High separation between inputs: > 20 dB
  • Gain adjustment
  • High level of shielding
  • Power supply : 12 V DC / 2 A (power supply included)
    Power consumption : 24W (max)
    Working temperature : 0 °C ... 50 °C
    Weight : 0.63 kg
    Dimensions : 192 x 185 x 50 mm
    Manufacturer / Brand : TELMOR
    Warranty : 2 years
