LANCOM CS-8132F-F2B
34 099,00 €
Monthly payment from 878.95 €
3521107 61909
4044144619090
Shipping 4-6 w.d.
Pay 5x6819.80€You are interested in this product?
As a central node in campus networks, the LANCOM CS-8132F core switch meets the requirements of today's and tomorrow's bandwidth-intensive applications. Especially for companies with many locations and very high data traffic, the 32 high-performance wire-speed 100G QSFP28 industry-standard ports with up to 6.4 Tbps switch capacity are the powerful backbone of the network. This makes the LANCOM CS-8132F ideal for use as a core switch in three-tier networks and for realizing switch architectures with 100% uptime. Intelligent functions such as Virtual Port Channel (VPC / MC-LAG), redundant and hot-swappable power supply and fan modules, a selectable ventilation concept, and a Limited Lifetime Warranty make this possible. If the switch is managed via the LANCOM Management Cloud, you benefit from standardized management and location-independent real-time monitoring of all network components. Alternatively, you can use the
Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1AX |
| Flow control support | Yes |
| Full duplex | Yes |
| Policy-based routing | Yes |
| Multicast support | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 12288 |
| Port mirroring | Yes |
| Number of VLANs | 4093 |
Management features | |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
Security | |
| Security algorithms | SNMP, SNMPv3, SNMPv2 |
| MAC address table | 32000 entries |
| System event log | Yes |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
Protocols | |
| Routing protocols | BGP4, OSPFv2, OSPFv3 |
| Management protocols | SNMP |
Design | |
| LED indicators | Yes |
| Product colour | Black |
Features | |
| Built-in processor | Yes |
| Processor frequency | 1600 MHz |
| Firmware upgradeable | Yes |
| Heat dissipation | 1060 BTU/h |
| Internal memory | 8192 MB |
Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions | |
| Width | 446 mm |
| Depth | 480 mm |
| Height | 43.8 mm |
| Weight | 7.44 kg |
Packaging data | |
| Package width | 540 mm |
| Package depth | 660 mm |
| Package height | 180 mm |
| Package weight | 7.45 kg |
Other features | |
| Form factor | 1U |
| Rack mounting | Yes |
Logistics data | |
| Country of origin | Taiwan |
| Customs product code (TARIC) | 85176200 |
Packaging content | |
| Manual | Yes |
