TP-Link Omada 5-Port Gigabit Easy Managed Switch
3356541 ES205G
8885020620917
In stock
The TP-Link Omada ES205G is a compact and silent 5-Port Gigabit Easy Managed Switch designed for small businesses, offices, and professional environments. With robust Layer 2 features, centralized Omada SDN management, and fanless operation, it delivers reliable performance in a durable and flexible form factor.
Hardware Features
5× 10/100/1000 Mbps RJ45 Ports with Auto-Negotiation and Auto MDI/MDIX
Fanless design for silent operation
Flexible installation: desktop or wall-mount
Physical security lock for enhanced protection
External power supply: 5 VDC / 0.6 A
Compact dimensions: 3.9 × 3.9 × 1.0 in (100 × 98 × 25 mm)
Surge protection up to ±6 kV
Performance
Switching capacity: 10 Gbps
Packet forwarding rate: 7.4 Mpps
MAC address table: 8K entries
Packet buffer: 4 Mbits
Jumbo frame support: up to 15 KB
Transmission method: Store-and-Forward
Software Features
Quality of Service (QoS)
Port-based / 802.1p / DSCP QoS
8 priority queues with WRR scheduling
Bandwidth control per port
Storm control (broadcast, multicast, unknown-unicast)
Layer 2 features
Static link aggregation
Loop prevention and loopback detection
802.3x flow control
Port mirroring (one-to-one, many-to-one, ingress/egress/both)
Port statistics and LLDP (802.1ab)
Layer 2 multicast
IGMP snooping v1/v2/v3 with fast leave
VLAN
MTU VLAN, port-based VLAN
802.1Q tag VLAN (up to 32 VLAN groups, 4K VID)
Management
Centralized control via Omada SDN
Supported controllers: Omada Hardware, Cloud-Based, or Software Controller
Omada App support for mobile management
Cloud access for remote monitoring and configuration
Zero-Touch Provisioning (ZTP) with cloud-based controller
Management features:
Web-based GUI
DHCP client
Cable diagnostics
Automatic device discovery
Batch configuration & firmware upgrading
Unified configuration
Other Information
Certifications: FCC, CE, RoHS
Package contents: ES205G switch, power adapter, installation guide, rubber feet
Operating environment:
Temperature: 0–40 °C (32–104 °F)
Storage: –40–70 °C (–40–158 °F)
Humidity: 10%–90% (operating), 5%–90% (storage), non-condensing
Design | |
| LED indicators | Yes |
| Product colour | Black |
Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions | |
| Width | 100 mm |
| Depth | 98 mm |
| Height | 25 mm |
Packaging data | |
| Package type | Box |
Other features | |
| Power over Ethernet (PoE) | No |
Certificates | |
| Compliance certificates | CE, RoHS, Federal Communications Commission (FCC) |
