Rebel RB-830 Multimetr
3308483 RB-830
5901890058087
Shipping 2-5 b.d.
Technical parameters:
- Manual change of measurement ranges
- Low battery indicator
- Polarity: automatic
- Sampling rate: 2 times per second
- Maximum reading: 1999
- Display size: 45 x 13 mm
- Operating temperature: 0 ° C ~ 40 ° with humidity <80%
- Storage temperature: -10 ° ~ 50 ° C with humidity <85%
- Power supply: 9 V battery
- Dimensions: 122 x 66 x 24 mm
- Weight: 107 g
Measuring ranges
- DC voltage: 200 mV, 2000 mV, 20 V, 200 V, 1000 V ± (1% + 5)
- alternating voltage: 200 V, 750 V ± (2% + 10)
- direct current: 200 µA, 2000 µA, 20 mA, 200 mA, 10 A ± (2% + 10)
- Resistance: 200 Ohm, 2000 Ohm, 20 kOhm, 200 kOhm, 2000 kOhm ± (1% + 4)
- Diode test
- HFE transistor test
Package contents: meter, measuring cables.
