Hismart PV Disconnect Panel, DC 4in-4out, External
369,00 €
Monthly payment from 10.40 €
2548454 NV820153
9990000820153
Shipping 2-4 days
Pay 5x73.80€You are interested in this product?
Features:
4 inputs 4 outputs 1000V DC.
DC junction box for 4-in/4-out PV system.
Designed for surge protection and isolation of the DC side of solar power.
Resistant to UV rays, water and dust IP66, impact IK10, non-flammable V0.
A set of MC4 connectors is included.
DC switch:
4 contacts, 1000V DC, 50A. (2 pcs.)
The DC switch doubles as a box door handle.
Patented DC extinguishing chamber.
Certifications: UI508i, IEC60947-3 Pv2.
DC SPD:
3 contacts, 1000V DC, 40kA. (4 pcs.)
Intended for the protection of photovoltaic cells.
Higher 20KA capacity (IEC, UL)
Response time <25ns.
Certificates: IEC 61643, UI1449.
Technical data:
Entrances: 4.
Exits: 4.
Maximum voltage: 1000V.
DC switch: 4P, 1000V, 50A. (2 pcs.)
DC SPD: 3P, 1000V, 40kA. (4 pcs.)
Short circuit current per input (Isc): 15A-30A (changeable).
Maximum output current: 50A.
Body material: 100% PC (polycarbonate).
Safety class: IP66 (waterproof and dustproof), IK10 (shockproof), V0 (fireproof).
Dimensions: 300x400x180 mm.
Input cable thicknesses: PG09, 2.5-16 mm.
Output cable thicknesses: PG21, 2.5-16 mm.
Operating temperature: -25°C to 60°C.
Warranty: 24 months
