Broadcom MegaRAID 9460-16i RAID controller PCI Express x8 3.1 12 Gbit/s
919,00 €
Monthly payment from 24.56 €
1394686 05-50011-00
0830343003600
Shipping 4-6 w.d.
Pay 5x183.80€You are interested in this product?
Broadcom’s Tri-Mode SerDes Technology enables the operation of NVMe, SAS or SATA devices in a single drive bay, allowing for endless design flexibility.
Ports & interfaces | |
| Host interface | PCI Express x8 |
| PCI Express slots version | 3.1 |
| Supported storage drive interfaces | Serial ATA, SAS |
Performance | |
| RAID levels | 0, 1, 5, 6, 10, 50, 60 |
| Mean time between failures (MTBF) | 3000000 h |
| Certification | AS/NZS CISPR 22, ICES -003, Class B, EN55022/EN55024, VCCI V-3, RRA no 2013-24 & 25, RoHS, N/IEC/UL 60950, CNS 13438, FCC 47 CFR part 15 Subpart B, class B, WEEE |
| Internal memory | 4096 MB |
| Internal memory type | DDR4 |
| Memory clock speed | 2133 MHz |
| Data transfer rate | 12 Gbit/s |
| S.M.A.R.T. support | Yes |
| SSD support | Yes |
| Number of devices supported | 255 |
| RAID Level Migration | Yes |
| Online Capacity Expansion | Yes |
| Chipset | SAS3516 |
System requirements | |
| Windows operating systems supported | Yes |
Operational conditions | |
| Operating temperature (T-T) | 10 - 55 °C |
| Storage temperature (T-T) | -45 - 105 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions | |
| Width | 155.7 mm |
| Depth | 68.9 mm |
Other features | |
| Connector(s) | 4 x Mini-SAS HD x4 SFF-8643 |
| Ports quantity | 16 |
Logistics data | |
| Harmonized System (HS) code | 84733080 |
Power | |
| Voltage | 3.3, 12 V |
| Power consumption (typical) | 17.02 W |
