PIR SENSOR DG85 PARADOX
87,46 €
Monthly payment from 3.15 €
3548452 DG-85
5902887018794
Shipping 2-5 b.d.
Pay 5x17.49€You are interested in this product?
Digital passive IR detector, resistant to animals up to 40 kg.
Thanks to advanced signal analysis algorithms, it is characterized by very stable operation and a low probability of false alarms.
| Usage : | For outdoor conditions |
| Pyroelement : | 2 x Double |
| Sensor type : | Passive IR (PIR) |
| Distance : | 11 x 11 m |
| Detection angle : | 90° |
| Recommended installation height : | 2.1 m |
| Sensitivity adjustment : | ✔ |
| Self-diagnosis : | - |
| Animal resistance : | < 40 kg |
| Pre-alarm function : | - |
| Maximum output load : | 28V DC / 100mA |
| Alarm outputs : | NC |
| Violation alarm time : | 5 seconds |
| Detected movement speed : | 0.2 ... 3.5 m/s |
| Digital temperature compensation : | - |
| Power supply : | 9 ... 16 V DC |
| Maximum current requirement : | 40 mA |
| Main features : | Fresnel lenses with UV filter Anti-sabotage security measures Patented motion analysis (without analog signal processing) Digital technology for pulse signal processing Digital Shield algorithm reduces false alarms Test mode EN 50131-2-2 Safety class II |
| Environmental class : | Class IV |
| Working temperature : | -35°C ... 50°C |
| Color : | White / Silver |
| Weight : | 0.218 kg |
| Dimensions : | 82 x 177 x 72 mm |
| Country of origin : | Canada |
| Manufacturer / Brand : | PARADOX |
| Warranty : | 2 years |
