AI-5 Signal Fire FIBER OPTIC WELDING MACHINE
AI-5 Signal Fire FIBER OPTIC WELDING MACHINE
AI-5 Signal Fire FIBER OPTIC WELDING MACHINE
AI-5 Signal Fire FIBER OPTIC WELDING MACHINE
AI-5 Signal Fire FIBER OPTIC WELDING MACHINE

Toote toon ja tegelik värvus võivad erineda pildil kujutatust, kuna pildid on illustratiivse iseloomuga. Samuti on toote kirjeldus üldine ega pruugi sisaldada kõiki toote omadusi.

AI-5 Signal Fire FIBER OPTIC WELDING MACHINE

1 299,00 €
Kuumakse alates 34.35
3594059

5902887094958

Tarneaeg 2-5 t.p.

Maksa 5x259.80€
Kogus
Kauba vastu huvi?
(Lugege teenusetingimusi)
Fiber alignment method :
  • 4 Engines
  • Thread positioning : centering to the core, centering to the shell
    Splicing time : 8 seconds
    Splice protector sleeve heating time : 15 s - possibility of your own settings
    Fiber optic type :
  • single-mode (SM) - G.652, G.657,
  • multimode (DM) - G.651,
  • DS/NZDS
  • Shell diameter : 80 ... 150 µm
    Average junction attenuation :
  • 0.02 dB (SM)
  • 0.01 dB (MM)
  • 0.04 dB (DS/NZDS)
  • Splicing mode : automatic, semi-automatic, manual
    Knife for cutting fibers : External (included), no built-in
    Visual fault catalog (VFL) of fiber optic cables :
  • Power : 15mW
  • 650 nm
  • steady on mode, flashing mode 2 Hz
  • Optical Power Meter (OPM) :
  • Optical wavelength : 850 nm, 1300 nm, 1310 nm, 1490 nm, 1550 nm, 1625 nm, 980 nm, 1270 nm, 1577 nm, 1650 nm
  • Measurement: -50 ... +30 dBm
  • Image zoom :
  • 320 x in the X and Y axes - single view
  • 160 x in the X and Y axes - double view
  • Supported splice protector sleeve lengths : 40mm, 60mm
    Mechanical strength test : 2 N
    Display : 5" TFT LCD
    MENU access : Bluetooth 4.2, Signalfire2 application
    Main features :
  • Quick start of the fusion splicer: 1 s
  • Case: Waterproof, Dustproof, Fall proof
  • Built-in automatic fiber cleaver
  • Battery :
  • capacity: 5200 mAh
  • ~ 160 splicing cycles
  • Typical battery charging time ~ 3 h
  • Power supply : 13.5 V DC / 4.8 A (power supply included)
    Conditions for proper operation :
  • Temperature: -15 °C ... +50 °C
  • relative humidity : < 95% (non-condensing)
  • Wind speed: max. 15 m/s
  • Altitude: 0 ... 5000 m
  • Languages supported : Polish, English, Arabic, Chinese, French, Spanish, Portuguese, Russian, Italian
    Weight :
  • 1.83 kg - welding machine
  • 3.5 kg - Toolbag + welding machine
  • Dimensions :
  • 193 x 140 x 120 mm - welding machine
  • 345 x 215 x 200 mm - Tool bag
  • Manufacturer / Brand : Signal Fire
    Warranty : 3 years
